H series chainsaws

INTENSIVE

MTH 510 / MTH 5100

INTENSIVE

Power/Displacement: 3.0 HP - 2.2 kW/50.9 cm³
Bar length (nose): 41-46-51 cm, 16"-18"-20", (sprocket)
Chain (pitch x gauge): .325’’ x .058’’ (20’’), Oregon .325” x .050’’ (16’’-18’’)
Oil Pump: automatic, adjustable, zero flow rate at idle speed
Oil/fuel tank capacity: 0.27 L/0.5 L
Sound pressure/power level: 110/113 dB(A)
Lh/rh vibration level: 5.2/4.8 m/s²
Dry weight without bar and chain: 5.4 kg

Data and figures are not binding due to the characteristics of the materials supplied as the products are subject to continuous technical improvements. The data regarding the practical use of the equipment and those of the technical characteristics, as described, may undergo variations without notice.
